Quick Details

Place of Origin:

Germany

Brand Name:

LaserTell

Model Number:

NL

IPL+ RF:

yes

After-sales Service Provided:

Online support

Type:

IPL

Certification:

CE ISO

Feature:

Acne Treatment, Anti-Puffiness, Blood Vessels Removal, Breast Enhancers, Dark Circles, Face Lift, Hair Removal, Pigment Removal, Pigmentation Correctors, Pore Remover, Skin Rejuvenation, Skin Tightening, Wrinkle Remover

Application:

For Commercial

Warranty:

2 Years

Keyword:

ipl lamp

Wavelength:

400-950nm

Product name:

IPL Xenon Lamp

Product Certification

CE Certified.

Valid from 2016-03-31 until 2021-03-30

Supply Ability

500 Set/Sets per Month

Packaging & Delivery

Packaging Details

Aluminum Packing Box with EPE Foam

Port

Beijing

Picture Example:

Lead Time :

Quantity(Sets)	1 – 10	>10
Est. Time(days)	3	To be negotiated

Product Description

Advantages:

1) Design consultancy with our product experts.

2) Customized prototype design and quotation. completed within 5 days

3) Lamp to lamp consistency.
4) High standards of manufacturing.
5) Long lifetime (300,000~1 million shots)
6) Patented cathode design.

Parameter

Dimension parameters

Lamp's bore (ID)=5mm
Lamp's Outside dia.(OD) =7mm
Lamp's Arc length (AL) =60±1.5mm
Lamp's Body length(BL) =120±2mm
O-ring centre (OC) =104mm
Pole dia. (PD) =2mm
Overall length (OAL)=480mm
wire length (WL) = 180mm

Technical Parameters

maximum average power=1,886W
maximum peak current =800A
operating voltage = 1,750V(max)
operating voltage =500V(min)
minimum trigger voltage =16KV
minimum trigger pulse=0.6μs
impedance constant= 15.84 Ko(Ω.A)
explosion energy constant = 73,680 (W./S)

Before & After

Detailed Images

Certifications

Packing & Delivery

Packaging
Packaging	Aluminium Package
Delivery	Within 5 Working Days
Packaging Details	The normal package is Aluminium Box with EPE Foam.  If export to remote countries, the wooden box will be added as well.  All parts packaged available according to customers special request.

LASERTELL

Our Service

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to install the machine, training how to use the machine.

* Engineers available to service machinery overseas.

* 24 hours + 7 days after-sale service and technical supports

* Lifelong Service (no matter 3 years or 5 years, or more…)
